Machining

Pedestal Grinder | Ironworker/Punch | Horizontal Band Saw | Injection Moulder | Vertical Metal Bandsaw | Belt Disc Sander | Drill Sharpener | Surface Grinder | End Mill Sharpener | Hardness Tester | Metal Lathe | Knee Mill | Drill Press Metal | Break Shear Roll

Pedestal Grinder

Pedestal Grinder

Baldor

1215W

Rotating abrasive wheels mounted on a pedestal and used to grind down metal objects. Ideal for sharpening and cleaning


Ironworker Punch

Ironworker/Punch

Baileigh

SW-95

Hydraulic tool to bend, cut, and punch metal. This 95-ton press can handle many demanding processes. It can also accommodate two users at the same time.


Horizontal Band Saw

Horizontal Band Saw

Wellsaw

1000

A machine tool with a vice to cut stock horizontally


Injection moulder

Injection Moulder

Morgan-Press

G-100T

Heats and injects plastic into molds. Its unique design was specially developed to make injection molding of plastic parts practical and economical in the quantities required for rapid prototyping and low-volume production. 6 cu. in. (4 oz.) max. single shot 20-ton max. clamping force (toggle). 12,000 psi max. injection pressure. 0-800°F (0-430°C) temperature control range  Mold plan area: 8″ x 11″ (maximum)






Vertical metal bandsaw

Vertical Metal Bandsaw

Jet

VBS-1610

Bandsaw for cutting metal or plastic. Heavy-duty bandsaw can handle large production pieces on its extra-large table. Multi-tilting worktable. Easy to read blade tension indicator. Variable speeds provide proper adjustments for high-efficiency cutting. Bi-Metal blade welder, grinder and cutter. Blade speeds 82-3,950. Max height capacity: 10 in. Throat capacity: 15.5 in. Table size (LxW): 22x24 in. Table tilt (Deg.) 8 F&B, 12 L & 15 R


Belt disc sander

Belt Disc Sander

Jet

J-4210K

Abrasive tool for multipurpose sanding and deburring


Drill Sharpener

Darex

Semi-automatic drill sharpener


Surface Grinder

Surface Grinder

Gardner

618

A precision tool with an abrasive wheel to provide better surface finish and flatness


End mill sharpener

End Mill Sharpener

Cuttermaster

MG-30

Use to sharpen milling cutters


Hardness Tester

Hardness Tester

TMI testing machines

UT-6

Hydraulic press for testing materials


Metal Lathe

Metal Lathes (2)

Nardini

MS 1440MS 1640

Machine tool stock is held in a chuck and rotated various cutting tools remove stock


knee mill

Knee Mills (2)

Supermax

YC-1 1/2VS-43 & YC-1 1/2VS-44

Vertical metal cutting mill. Table size – 9” x 42”. Longitudinal travel (x-axis) – 30”. Cross Travel (y-axis) – 12”. Vertical Knee Travel (z-axis) – 16”.  RAM Travel – 12” Turret Rotation – 360 degrees.  Speeds – 80-2720RPM. Equipped with power table feed.


Metal Drill Press

Drill Press Metal

Powermatic

1150

Drill Press is perfect for boring accurate holes in metal. Has 15-inch throat, Variable speed 300-4800 rpm,  15x21 production table, and Rockwell 1/2hp single phase 1725 rpm motor.


Brake Shear RollBreak Shear Roll

Enco

3in1 Machine (30" Shears, 30"PressBrake,1-1/2"Dia. Slip Roll)
