Vacuum Press



Vacuum Press

Vac-u-clamp

Mark X

The Pro-10 includes a 10 cfm automatic pump, 54" x 109" poly bag, 5-micron filter, 10' hose and manual. The universal choice of both professionals and experienced amateurs, the Pro10 is a heavy-duty workhorse, especially for those shops where lamination and forming are part of everyday production.

Features
-Dual mode switch for bagging in auto mode or run full time for clamping
-Fully automatic vacuum-level maintenance
-Adjustable vacuum level for application or altitude requirements
-Quick disconnect vac hose connection
-20 mil poly bag with exclusive c-bar closure system
-High micron cleanable filter
-All upfront controls and hose connections

Specifications
-Dimensions: 10" x 10" x 22"
-Shipping wt.: 78 lbs
-10 cfm, 3/4 hp, 120 vac 24"-26" vacuum level
-Thermal overload protection
-Powder-coated steel case
-Quick disconnect vac hose
Multi-bag operation with optional manifold
